推进式（插入推锁式）软管接头 PUSH-ON FITTING应用范围：各种油路、气路、水路，特别适合汽车装配线，模具等需要快速、便捷使用或更...
用于扣压软管总成，和我们接头可以严格配套使用。如果用户需要单独购买套筒，需要提供打算配套使用的接头样品或图纸及...
DIN 2817内螺纹光滑管尾接头 GI
| Part no. | Material | Size | For hose | Thread | Thread seal | SW | Weight |
| mm | mm | Kg/pcs | |||||
| GI013S6 | SS316 | 1/2" | 13 | G1/2 | PTFE | 24 | 0.10 |
| GI019S6 | SS316 | 3/4" | 19 | G3/4 | PTFE | 30 | 0.15 |
| GI025S6 | SS316 | 1" | 25 | G1 | PTFE | 36 | 0.16 |
| GI032S6 | SS316 | 1-1/4" | 32 | G1-1/4 | PTFE | 46 | 0.18 |
| GI038S6 | SS316 | 1-1/2" | 38 | G1-1/2 | PTFE | 55 | 0.29 |
| GI050S6 | SS316 | 2" | 50 | G2 | PTFE | 65 | 0.44 |
| GI063S6 | SS316 | 2-1/2" | 63 | G2-1/2 | PTFE | 85 | 0.75 |
| GI065S6 | SS316 | 2-1/2" | 65 | G2-1/2 | PTFE | 85 | 0.75 |
| GI075S6 | SS316 | 3" | 75 | G3 | PTFE | 100 | 1.12 |
| GI080S6 | SS316 | 3" | 80 | G3 | PTFE | 100 | 1.12 |
| GI100S6 | SS316 | 4" | 100 | G4 | PTFE | 125 | 3.90 |
